A metal and walnut letter opener, whose elongated, faceted blade connects to a wooden handle shaped like a heraldic shield.
Original size 2400x1600
Blender model
The letter opener draws attention to the brief, elegant gesture of opening an envelope.
Original size 1672x941
Original size 1672x941
The body is made of AISI 304 stainless steel, featuring wide, satin-finished edges and narrow, polished edges and perimeter.Two walnut inlays retain the wood’s longitudinal grain; a transparent matte oil with wax is used for the final finish.
Original size 1671x941
An option with engraving on the metal edge is available.The other images show the model without any labeling.
Technical Specifications:
— 3D Model Dimensions: 283,4 × 29,1 × 10.3 mm.
— Wooden Handle Length: 108.4 mm.
— Construction: Solid metal body with a tang and two wooden caps.
— Purpose: Opening envelopes; blade edges are blunted.
— Required Assembly: Two concealed pins, Ø2 × 8 mm, and epoxy adhesive.
— Marking Size in Separate Variant: 25 × 6.87 mm; recess depth — 0.18 mm.
— Project Stage: Digital modeling and visualization in Blender.
Fabrication:
The project involves separate milling of the metal casing and the wooden overlays, rounding of the edges, surface finishing, and assembly.The method for applying recessed markings will be determined during the preparation phase of fabrication.
